| Datasheets & Specifications | ||
| Series | CSF | |
| Size | 25 | |
| Ratio | 50 | |
| Type | 2UH | |
| Rated Torque L10 | 39 | Nm |
| Limit for Average Torque | 55 | Nm |
| Limit for Repeated Peak Torque | 98 | Nm |
| Limit for Momentary Peak Torque | 186 | Nm |
| Starting Torque | 15 | Ncm |
| Backdriving Torque | 9 | Nm |
| Ave. Input Speed | 3,500 | rpm |
| Standard Accuracy | 1 | arc min |
| Mass / Weight | 1.50 | KG |
| CSF-14-30-2UH | CSF-25-50-2UH |
| CSF-14-50-2UH | CSF-25-80-2UH |
| CSF-14-80-2UH | CSF-25-100-2UH |
| CSF-14-100-2UH | CSF-25-120-2UH |
| CSF-17-30-2UH | CSF-25-160-2UH |
| CSF-17-50-2UH | CSF-32-30-2UH |
| CSF-17-80-2UH | CSF-32-50-2UH |
| CSF-17-100-2UH | CSF-32-80-2UH |
| CSF-17-120-2UH | CSF-32-100-2UH |
| CSF-20-30-2UH | CSF-32-120-2UH |
| CSF-20-50-2UH | CSF-32-160-2UH |
| CSF-20-80-2UH | CSF-40-50-2UH |
| CSF-20-100-2UH | CSF-40-80-2UH |
| CSF-20-120-2UH | CSF-40-100-2UH |
| CSF-20-160-2UH | CSF-40-120-2UH |
| CSF-25-30-2UH | CSF-40-160-2UH |
